The radio incorporates a built-in test sequence which automatically checks transceiver performance and displays results.
A 16 Kbits/s data capability is also incorporated in the transceiver and options extend the facilities to include built-in pseudo-white-noise encryption of both data and speech.
The front panel which is removable provides full-control over a simple serial data line. It can be relocated and mounted anywhere on a tank with a radio located in the hull or a similar remote position. The control panel also provides control of two radios from a single remote position.
The control panel enables selection of operating frequency and up to nine pre selected channels as well as encryption codes and the transceiver mode. An alphanumeric display gives read-out of frequency and status.
First announced in September 1979, the VRM5080 was in production by Racal Radio Ltd in Reading, England for users worldwide and by Kapsch for the Austrian Army. These radios are supplied in good used condition, tested and operational Grade 2.
TECHNICAL SPECIFICATION
Mode: F3E narrowband FM simplex
Frequency range: 30-76 MHz
Number of channels: 1841 with 9 pre-programmable
Channel Spacing: 25 kHz spacing
Power Output: High Power: 50 Watts, Medium Power: 10 Watts, Low Power: 5 mW
Power Supply: 24 V DC (nominal) negative earth
Power Consumption: high power: 7.5 A max, low power: 1.5 A max
Temperature Range, Operating: -40 to + 70?C
Temperature Range, Storage: -40 to + 70?C
Weight: 13.5 kg
The internal X & Gamma sensor is easily removable and is capable of measuring from 1 Milli Rad per hour up to 1000 Rads per hour.
Six measurement ranges by direct reading on a single scale. The scale is illuminated for night reading.
Overall, it is a very sensitive Geiger counter that is portable and self contained, it is robustly built and designed to take a lot of abuse.
The DOM-410 Counter is powered by two standard 1.5 Volt D cells and is supposed to last up to 16 hours on a fresh set of batteries.
The DOM-410 counter is supplied in very good working condition with-out any accessories. Some accessories and English language manual are available separately.
Operates from 24 VDC vehicle battery or power supply. Transmitter output power 8W (low) and 35W (high).
Noise-operated squelch as well as an advanced tone-operated squelch (150 Hz) is provided. The tone squelch provides reliable retransmission when two receiver-transmitter are used as an automatic relay station.
The AN/VRC-12 is a combat-proven vehicular radio set that lends its self particularly well to applications of tactical deployment and specific operational missions because of their ability to be assembled into various configurations and of being installed on most types of military vehicles such as M-151 Mutt Jeeps, Humvees, heavy armour, etc.
The RT-524 is supplied in good working order Grade 2. Some Accessories and cables are also available.
These radios are supplied in very nice condition and include the test certificate.
The Centronics pin-out is:
Pin-1 Negative & case (GND)
Pin-2 Radio +ve (+28 Volts)
Pin-3 PTT
Pin-19 Panel Bulb +ve (+28 Volts)
Pin-21 & Pin-22 Audio output
The R-442/VRC is supplied in good working order Grade 2. Some accessories and cables are also available.
